How to Use HRV to Predict Illness

BY Simon Wegerif

Nobody wants to deal with illness or injury. Here are a few ways to use HRV to understand your body's response to stress and avoid both.

Nobody likes having to take time out from training after getting sick; especially during intensive training blocks or in the run-up to an important event. Missing planned training can severely compromise your chances of completing or reaching your goals.

What does the research show us?

Researchers in Finland analyzed the relation between medal-winning success and days sick in cross country skiers during the run-up to the last winter Olympics. They found that while medal-winners spent an average of 14 days per year with colds and other respiratory infections, less successful athletes spent an average of 22 days out sick with similar infections.

Similarly, a study conducted by the Australian Institute of Sport on track and field athletes over five seasons found that illness and injury that prevented or limited training were major factors in determining success.

On the positive side, athletes who completed 80% or more of their planned training were seven times more likely to reach their goals and succeed in events compared to those that did not.

They also found that most illnesses were associated with overtraining, and that 50% of illnesses occurred in the two months prior to competition when training loads and mileages are highest.

So why do heavy training loads make you more likely to become sick?

One of the key reasons is resilience. As the chart below, taken from the International Olympic Committee statement on load in sport and risk of illness shows, as loads are ramped up, the risk of illness increases rapidly in recreational and age group athletes. Elite athletes, partly due to their genetic makeup, and partly by being conditioned to high weekly loads, are more resilient, and don’t get sick so easily when loads are ramped up. In fact, they are more likely to become sick when training loads are reduced and they become deconditioned.

As training loads are ramped up, recovery demands increase too, especially the need for good quality sleep and nutrition. If training loads and recovery demands are not in balance, inflammation starts to become chronic, and the immune system gets stressed trying to repair too many parts of the body at once. It’s at this point that viruses and bacteria that would normally be swiftly identified and dealt with can much more easily take hold and cause illnesses such as coughs, colds, sore throats and potentially bacterial chest, lung and stomach infections.

How does illness affect the way you can train?

Once symptoms appear, it’s important to reduce training loads so that the body has a chance to recover, but when do you need to stop, and how soon can you safely return to lighter training? Many people look at the location and severity of symptoms for guidance, such as whether a cold is only above the neck as a sign that training can be resumed, but in fact there are important and useful sub-clinical indications such as Heart Rate Variability that can be measured non-invasively and deliver more useful guidance.

What is Heart Rate Variability?

Heart rate variability (HRV) is a reliable method used for assessing the effects of stress on your body. High HRV is increasingly linked to good health and a high level of fitness, while decreased HRV is linked to stress, fatigue and even burnout. By knowing when your body is fatigued, you can quickly adjust your workouts to avoid overtraining.

Used in many health and high-performance contexts, HRV measures in athletes most commonly take the form of a short waking measure, where HRV is compared to a personal baseline and colored indications used to guide the athlete as to how recovered they are. Good HRV software, such as ithlete, encourages the athlete to record wellness metrics and import training loads e.g. TSS from TrainingPeaks to give a complete picture for the athlete and their Coach. The context details help the athlete and their Coach understand which training and lifestyle factors are causing the higher recovery demand and therefore how best to address it.

How can Heart Rate Variability detect illness?

HRV is good for detecting illness because it is sensitive to how stressed the body is at that moment. HRV directly taps into the balance between the stress (fight or flight) sympathetic and the parasympathetic (rest or digest) branches of the nervous system.

Lower HRV indicates that the body is more stressed. Although you might expect that different kinds of stress e.g. physical, mental, nutritional, affect your body differently, in fact at the base level they affect the nervous system in very similar ways. So if you are mentally or emotionally stressed and you eat poorly (e.g. seeking comfort foods) your ability to handle training stress is much reduced.  There is an entire series here on managing Total Load.

Detecting the start of illness

The example below shows a typical HRV chart for an experienced recreational athlete with a low resting heart rate between 50-60bpm (red dashed line), and a high level of HRV ~100 (blue baseline). The colored dots are the daily HRV training indications i.e. Green = go, Orange = caution, Red = stop. The vertical black bars are TSS, imported from TrainingPeaks.

The emojis show when this athlete started to feel unwell, and their HRV fell rapidly at the start of illness. Significantly, their resting heart rate only rose above its normal range on the 3rd day after the illness had begun. In other words, HRV is a more sensitive and faster-acting indicator, because it taps directly into the nervous system.

On the 6th day after the illness began, the daily HRV indication turned from Red to Orange, and the athlete began training again with a light load for the next 3 days as they felt better.

The chart below shows HRV data from world tour cyclist Mathew Hayman in his last competitive season before he retired as a professional (see also Mathew Hayman Career Analysis).

Source: Powerhouse Cycling

Here the red line represents average heart rate, while the green line representes HRV.

During the build-up to Paris Roubaix 2018, Mat twice caught respiratory infections. His HRV dropped rapidly when this happened, and his Coach used the ithlete Team dashboard to identify when Mat’s training loads needed to be modified in order to let him recover. In both cases, he did recover quickly after just 2-3 days, illustrating the point about elite athletes having high resilience levels and the importance of adjusting training quickly to facilitate recovery!

Using HRV to identify when illness & injury are more likely

As well as looking at trends on an HRV Timeline chart, by plotting an athlete’s HRV (horizontal) and resting heart rate (vertical) against each other on the same chart, we can see when their reserves are lower and contracting infections more likely.

  • When the body is coping well with training loads, the green bubble on the ithlete Training Guide chart below will be close to the center or a little towards the bottom right as resting heart rate lowers.
  • If recovery is impaired and not sufficient, the bubble will be in the orange region to the left of the center. A little way into this region is OK, as it shows the body is getting the stimulus to adapt.
  • If the bubble created from the daily HRV measurement heads towards the top left, and becomes red, that shows the athlete’s body is stressed and illness is more likely to be able to take hold.
ow to use the ithlete Pro Training Guide

Conclusion

Sickness during planned training blocks or the build-up to an important event can make the difference between success and failure in reaching your goals.

High training loads combined with insufficient recovery can promote chronic inflammation and weaken the immune system. HRV is a sensitive marker of stress and recovery, and can be used to identify when you are starting to get sick, so that training loads can be reduced, and extra attention paid to sleep and nutrition. HRV can also be used to show when you are on the mend, so you miss the minimum number of training sessions.

References:

Schwellnus M, Soligard T, Alonso J-M, et al. Br J Sports Med 2016;50:1043–1052.

Raysmith BP, Drew MK. Performance success or failure is influenced by weeks lost to injury and illness in elite Australian track and field athletes: A 5-year prospective study. J Sci Med Sport (2016) Valtonen M, Waris M, Vuorinen T, et al. Common cold in Team Finland during 2018 Winter Olympic Games Br J Sports Med 2019;53:1093–1098.
